Battery storage rack (240 V) – 3D model preview

Battery storage rack (240 V)

Téa · Electrical · 3D model · Updated 30 Oct 2026

Open in 3D

  • Procedures2shared publicly
  • Views5all time
  • Rating–No ratings yet
  • Likes0from the Community

0 comments

Procedures

Rack assembly

Assembly · 6 steps · No ratings yet

6 steps

  1. Attach Rack Supports to Base

    Start by attaching the four rack supports to the rack base.

  2. Attach Tray Supports to Base

    Then attach the four tray supports to the base.

  3. Attach Rack Top and Rear Door

    Fit the rack top onto the supports, then attach the rear door. The rack frame is now complete.

  4. Install All Tray Slots

    Install all of the tray slots into their respective positions.

  5. Insert all Trays

    Slide each highlighted tray into its slot until it sits fully home and level.

  6. Insert the Battery Assemblies

    Insert the battery assembly into its designated position. Battery modules are heavy and store energy: lift them with two people or a lift aid, keep the terminals covered until connection, and never let tools bridge the terminals. These are 240 V modules: electrical connection must be done de-energized by a qualified electrician.

Quality Gate

Quality Control · 3 steps · No ratings yet

3 steps

  1. Inspect rack assembly

    Visually inspect the rack from all sides to confirm it is properly assembled and installed in the structure.

  2. Verify clear module access

    Ensure there are no tools, cables, or components blocking access to the module area before proceeding.

  3. Clear work area

    Remove any tools and packaging materials from around the rack to maintain a clean and safe workspace.
